| CPU | NVIDIA® Jetson AGX Orin™ 64GB – 275 TOPS (2048 CUDA® cores GPU + 12-core Arm Cortex-A78AE CPU + 64 GB LPDDR5) NVIDIA® Jetson AGX Orin™ 32GB – 200 TOPS (1792 CUDA® cores GPU + 8-core Arm Cortex-A78AE CPU + 32 GB LPDDR5) |
|---|---|
| Netowrk | Marvell® Industrial 10GbE, Intel® Industrial 2.5GbE |
| Security | Security Boot, Arm TrustZone |
| Ethetnet | Marvell® Industrial 10GbE, Intel® Industrial 2.5GbE (3 x Phoenix Contact® M12 X-coded connectors) |
|---|---|
| USB | 2 x USB Type-A/IP67 connector for USB 3.2 *One port share 10Gbps bandwidth |
| Video Output | 1 x HDMI Type-A/IP67 connector for HDMI 2.1 output |
| Audio | 1 x HD Audio from the HDMI |
| Serial Port | 1 x M12 A-coded connector for RS-232/422/485 |
| CAN Bus | 2 x M8 A-coded connectors for CAN FD |
| Mgmt. Port | 1 x USB Type-C for System Recovery (Device only) |
| Camera | 4 x FAKRA-Z connectors for GMSL-2 cameras |
| SIM Card | 1 x Nano SIM Card Slot |
| M.2 | 1 x M.2 3042/52 Key B slot (USB3.0) with a Nano SIM Card Slot 1 x M.2 2230 Key E slot * Thermal solution is required for M.2 5G Module |
|---|---|
| mPCIe | 1 x mPCIe Full-size slot (USB 2.0 supported) |
| Type | 1 x 64GB eMMC (Built-in within SoM) 1 x M.2 2280 Key M slot supports NVMe SSD (Pre-installed) |
|---|
| Operating System / SDK | NVIDIA® JetPack including Jetson Linux, NVIDIA® development tools |
|---|
| Supply voltage | 1 x Phoenix Contact® M12 K-coded connector for DC-IN 9~60V |
|---|---|
| Power Protection | OCP, OVP, Surge and Reversed Polarity Protection |
| Power Management | Ignition Detection with Smart Power Management |
| RTC Battery | High-capacity coin cell battery for RTC |
| UPS (Option) | Backup battery for system power backup |
| Dimension | 300(L) x 190(W) x 77.5(H) mm |
|---|---|
| Weight | 5,100g (Barebone) |
| Construction | Aluminum Alloy |
| Mounting | Wall Mount |
| Ingress Protection | IP66 |
| Relative Humidity | 10% RH – 90% RH (non-condensing) |
|---|---|
| Operating Temp. | -25°C ~ 70°C w/0.6 m/s airflow (for barebone system) *Operating temp. varies by accessories installed. |
| Storage Temp. | -40°C ~ 85°C |
| Vibration | MIL-STD-810G, Method 514.6, Procedure I, Cat.4 (Operating) IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis |
| Shock (with SSD) | MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi-trailers=15G (11ms) with SSD (Operating) |
| Certification | CE, FCC Class A, E-Mark, ECE R118, EN50155*, EN45545-2 (R25) *On going |
