| CPU | NVIDIA® IGX Thor™ 14-core Arm® Neoverse V3AE |
|---|---|
| GPU | NVIDIA® IGX Thor™ 2560-Core NVIDIA Blackwell Architecture GPU with 96 5th Gen Tensor Cores |
| 5581 FP4 TFLOPSRTX Pro 6000 Blackwell Max-Q Workstation 96 GB GDDR7 Memory, 1792 GB/s Memory Bandwidth 24064-Core NVIDIA Blackwell Architecture GPU |
|
| AI Performance | 5581 FP4 TFLOPS |
| System Memory | 128GB LPDDR5X |
| Storage | 4×SATA |
|---|---|
| Display Interface | 4×DP1.4a |
| Ethernet | 2×100Gb QSFP112 Port 2×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | PCIe 1×PCIe Gen5×16 Slot (With 8 PCIe Lanes) |
| M.2 1×M.2 2230 E Key USB2.0/PCIe Gen2×1 Slot 1×M.2 2280 M Key PCIe Gen5×2 Slot |
|
| USB | 4×USB3.2 Gen2 (Type-A) 1×USB3.2 Gen2 (Type-C) |
| MIPI | 16×MIPI CSI Lanes (Support MIPI Camera, Capture Card) |
| Audio | 1×3.5mm Line Out 1×3.5mm MIC in |
| Perherial Communication | 4×COM Port (Pin Header) 1×GPIO (Pin Header) CAN Bus (Pin Header) |
| Misc. Features | Firmware Upgradable |
| Type | NVIDIA RTX 6000 Ada |
|---|
