- Powered by NVIDIA® Jetson AGX Orin™ up to 275 TOPS
- 2×PCIe Gen3×4
- 3×M.2 M Key / 1×M.2 E Key / 1×M.2 B Key
- 1×SFP+
- 2×USB3.2 Gen1
- CAN Bus / UART / I2C / SPI
| CPU | NVIDIA® Jetson AGX Orin™ 32GB 8-core Arm® Cortex®-A78AE v8.2 64-Bit CPU 2MB L2 + 4MB L3 NVIDIA® Jetson AGX Orin™ 64GB 12-core Arm® Cortex®-A78AE v8.2 64-Bit CPU 3MB L2 + 6MB L3 |
|---|---|
| GPU | NVIDIA® Jetson AGX Orin™ 32GB 1792-Core NVIDIA Ampere Architecture GPU with 56 Tensor Cores NVIDIA® Jetson AGX Orin™ 64GB 2048-Core NVIDIA Ampere Architecture GPU with 64 Tensor Cores |
| API Performance | NVIDIA® Jetson AGX Orin™ 32GB 200 TOPS NVIDIA® Jetson AGX Orin™ 64GB 275 TOPS |
| System Memory | NVIDIA® Jetson AGX Orin™ 32GB 32GB LPDDR5 NVIDIA® Jetson AGX Orin™ 64GB 64GB LPDDR5 |
| Storage | 64GB eMMC 5.1 (On NVIDIA® Jetson AGX Orin™ Module) |
|---|---|
| Display Interface | 2×HDMI2.0 1×DP **Select 2 Video Output Port at Same Time |
| Ethernet | 1×RJ45 for 10/100/1000Mbps Ethernet 1×SFP+ for 10Gbps Ethernet (With Add-On Fiber Board) DHCP Client |
| Expansion Slot | PCIe 1×PCIe Gen3×4 Slot(*) 1×PCIe Gen3×4 Slot(**) M.2 1×M.2 2230 E Key PCIe Gen4*1/USB2.0/SDIO Slot 1×M.2 2280 M Key PCIe Gen4×4 Slot 1×M.2 2280 M Key PCIe Gen4×4 Slot(*) 1×M.2 3080 M Key PCIe Gen4×4 Slot(**) 1×M.2 2242/3042/3052 B Key USB3.2 Gen1 Slot * Please select either 1×PCIe Gen3×4 Slot or 1×M.2 2280 M Key PCIe Gen4×4 Slot to use ** Please select either 1×PCIe Gen3×4 Slot or 1×M.2 3080 M Key PCIe Gen4×4 Slot to use |
| USB | 2×USB3.2 Gen2 (Type-A) 2×USB3.2 Gen1 (Pin Header) 2×USB2.0 (Type-A) |
| MIPI | 16×MIPI CSI-2 Lanes ( D-PHY 2.1, 4×4 | 3×4+2×2 | 2×4+4×2 | 1×4+5×2 | 6×2 MIPI Lanes, Support MIPI Camera, Capture Card ) |
| Audio | 1×3.5mm Line Out 1×3.5mm MIC In |
| Perherial Communication | 40Pin Header 1×UART (Pin Header) 3×GPIO (Pin Header) 2×CAN Bus (Pin Header or Wafer) 2×I2C (Pin Header) 1×SPI (Pin Header) 3×PWM (Pin Header) 4×Fan Connector 1×RS232 Wafer 1×RS485 Wafer |
| Misc. Features | Firmware Upgradable |
