Pixel Panel PC

System

CPU	NVIDIA® Jetson AGX Orin™ 32GB 8-core Arm® Cortex® -A78AE v8.2 64-Bit 2MB L2 + 4MB L3
	NVIDIA® Jetson AGX Orin™ 64GB 12-Core Arm® Cortex® -A78AE v8.2 64-Bit 3MB L2 + 6MB L3
	NVIDIA® Jetson AGX Orin™ Industrial 12-Core Arm® Cortex® -A78AE v8.2 64-Bit 3MB L2 + 6MB L3
GPU	NVIDIA® Jetson AGX Orin™ 32GB 1792-Core NVIDIA Ampere Architecture GPU with 56 Tensor Cores
	NVIDIA® Jetson AGX Orin™ 64GB 2048-Core NVIDIA Ampere Architecture GPU with 64 Tensor Cores
	NVIDIA® Je tson AGX Orin™ Industrial 2048-Core NVIDIA Ampere Architecture GPU with 64 Tensor Cores
AI Performance	NVIDIA® Jetson AGX Orin™ 32GB 200 TOPS
	NVIDIA® Jetson AGX Orin™ 64GB 275 TOPS
	NVIDIA® Je tson AGX Orin™ Industrial 248 TOPS
Sytem Memory	NVIDIA® Jetson AGX Orin™ 32GB 32GB LPDDR5
	NVIDIA® Jetson AGX Orin™ 64GB 64GB LPDDR5
	NVIDIA® Je tson AGX Orin™ Industrial 64GB LPDDR5 (+ECC)

Interface

Stoarge	64GB eMMC 5.1 (On NVIDIA® Jetson AGX Orin™ Module) Supports External NVMe 1×SD Card Slot
Display Interface	1×HDMI2.0
Ethernet	1×RJ45 for 10/100/1000Mbps Ethernet DHCP Client
Expansion Slot	1×M.2 2280 M Key PCIe Gen4×2 Slot 1×M.2 2280 M Key PCIe Gen4×1 Slot
USB	2×USB3.2 Gen2 (Type-A), 1×USB2.0 (Type-A)
MIPI	16×MIPI CSI CSI-2 Lanes (D-PHY 2.1, 4×4 | 3×4+2×2 | 2×4+4×2 | 1×4+5×2 | 6×2 MIPI Lanes, Support MIPI Camera, Capture Card)
Audio	1×3.5mm Line In, 1×3.5mm Line Out
Peripherals	D-Sub Connector 1×RS232, 1×UART Phoenix Connector 4×GPIO 1×CAN Bus (Pin Header)
Misc. Feature	Firmware Upgradable

Screen Feature

Size	10 inch
Resolution	1280x800
