- 12th Gen Intel Core™ i3/i5/i7 processor
- Supports high speed DDR5 memory & NVMe
- Fanless and cableless design
- 1U compact chassis
- Comply with IEC 60601-1-2 medical standards
- Optional Wi-Fi 6E & Bluetooth module
| Processor | 12th Gen Intel® CoreTM i3-1215UE processor 12th Gen Intel® CoreTM i5-1245UE processor 12th Gen Intel® CoreTM i7-1265UE processor |
|---|---|
| Memory | 2x DDR5 SO-DIMM 4800 up to 64GB |
| Storage | 1x M.2 NVMe with PCIe x4 for SSD 1x SATA 3.0 |
| BIOS | AMI uEFI BIOS (SPI ROM) |
| Expansion | Optional 1x M.2 Key E 2230 Support Intel Wi-Fi 6E and Bluetooth Module |
| Serial Port | 2x RJ-45 COM ports |
|---|---|
| USB | 4x USB 3.2 (Type-A) 5x USB 2.0 (Type-A) |
| Audio | Realtek ALC 897 Audio Codec MIC In/Line-out |
| Ethernet | 2x Intel I226LM With 2.5G Gigabit LAN |
| Display | 1x HDMI® up to 4K resolution 1x DP up to 8K resolution |
| Power Input | DC 12~24V DC input |
|---|
| Operation Temp. | -5°C ~ 40°C |
|---|---|
| Storage Temp. | -40°C ~ 70°C |
| Dimension | 152(W) x 196(D) x 44(H) mm |
| Weight (Net) (kg) | 0.688 |
