| CPU | NVIDIA Jetson Orin NX 8GB 6-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 1.5MB L2 + 4MB L3 |
|---|---|
| NVIDIA Jetson Orin NX 16GB 8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 2MB L2 + 4MB L3 |
|
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| API Performance | NVIDIA Jetson Orin™ NX 8GB, 70 TOPS |
| NVIDIA Jetson Orin™ NX 16GB, 100 TOPS | |
| System Memory | NVIDIA Jetson Orin™ NX 8GB, 8GB LPDDR5 |
| NVIDIA Jetson Orin™ NX 16GB, 16GB LPDDR5 |
| Storage | Supports External NVMe 1×Micro SD Card Slot |
|---|---|
| Display Interface | 1×Mini DP1.4 |
| Ethernet | 1×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | M.2 1×M.2 2230 M Key PCIe Gen4×2 Slot 1×M.2 2230 E Key PCIe Gen4×1 Slot |
| USB | 1×USB3.2 Gen2 (Type-C) 1×USB3.2 Gen1 (Type-A) |
| Peripheral Communication | 14 Pin Header 1×USB2.0 4×GPIO 1×UART 1×I2C 8 Pin Pheonix Connector (CON1) 1×GPIO 1×RS232 1×RS485 8 Pin Pheonix Connector (CON2) 1×GPIO 2×I2C |
| Misc. Features | Firmware Upgradable |
